Automatic Blow Molding Machine - Double-layer Double-color co-extrusion with view-stripe

WLCPJ系列-自动挤出吹塑机-双层双色带液位线双工位机型-技术参数 WLCPJ series-Automatic Plastic Extrusion Blow Molding Machine - Double-layer Double-color with View Stripe Double-station Models - Technical Parameters
型号MODEL		60+40+25I	70+40+25I	75+40+25I	65+40+25II	70+45+30II	75+50+30II	80+60+30Ⅱ
制品最大容量MAX.CAPACITY OF PRODUCTIONS	L	2	4	6	1.0×2	2.0×2	4.0×2	5.0×2
模头中心距离CENTRAL DISTANCE OF DIE HEAD	mm	-	-	-	120	180	240	240
螺杆直径SCREW DIAMETER	mm	604025	704025	754025	654025	704530	755030	806030
螺杆长径比SCREW LENGTH/DIAMETER RATIO	L/D	25/1 25/1 20/1	25/1 25/1 20/1	25/1 25/1 20/1	25/1 25/1 20/1	25/1 25/1 20/1	25/1 25/1 20/1	25/125/120/1
挤出量EXTRUSION VOLUME(PE)	kg/h	70	90	100	75	100	120	140
锁模力MOULD CLAMPING FORCE	kN	45	50	60	50	60	90	60
模板尺寸(宽×高)MOULD PLATE DIMENSIONS(W×H)	mm	350×350	400×380	400×380	350×350	400×380	520×400	520×450
开模行程OPENING STROKE	mm	250	280	280	250	280	300	300
主电机功率MOTOR POWER	kW	154.01.1	224.01.1	304.01.1	18.54.01.1	225.51.5	307.51.5	37151.5
总功率GENERAL ASSEMBLY POWER	kW	40	52	58	48	52	76	95
主机外形尺寸(长×宽×高)APPEARANCE(L×W×H)	mm	3100×2500×2300	3200×2800×2400	3500×2800×2600	3100×2500×2300	3200×2800×2600	3600×3000×2800	4200×3200×3300
机器重量WEIGHT	kgs	4600	5200	5500	4600	5500	7500	8500
注：由于产品不断改进，以上数据仅供参考，如有更改恕不另行通知。
Note: Due to continuous product improvement, data above is only for reference, such as are subject to change without a separate notice.
