Automatic Blow Molding Machine - Single-layer Single-color extrusion with view-stripe

WLCPJ系列-自动挤出吹塑机-单层单色带液位线双工位机型-技术参数 WLCPJ series - Automatic Plastic Extrusion Blow Molding Machine-Single-layer Single-color with View Stripe Double-station Models - Technical Parameters
型号MODEL		50+25I	60+25I	70+25I	75+25I	55+25II	65+25II	70+25II	75+30II
制品最大容量MAX.CAPACITY OF PRODUCTIONS	L	1.0	2.0	3.0	6.0	0.6×2	1.0×2	1.5×2	2.0×2
模头中心距离CENTRAL DISTANCE OF DIE HEAD	mm	-	-	-	-	120	120	160	180
螺杆直径SCREW DIAMETER	mm	5025	6025	7025	7525	5525	6525	7025	7530
螺杆长径比SCREW LENGTH/DIAMETER RATIO	L/D	25/120/1	25/120/1	25/120/1	25/120/1	25/120/1	25/120/1	25/120/1	25/120/1
挤出量EXTRUSION VOLUME(PE)	kg/h	35	60	75	85	45	65	75	90
锁模力MOULD CLAMPING FORCE	kN	32	40	50	60	40	45	50	60
模板尺寸(宽×高)MOULD PLATE DIMENSIONS(W×H)	mm	260×240	350×350	400×380	400×380	320×290	350×350	400×380	410×380
开模行程OPENING STROKE	mm	150	250	250	280	200	250	250	280
主电机功率MOTOR POWER	kW	7.51.1	18.51.1	221.1	301.1	111.1	18.51.1	221.1	301.5
总功率GENERAL ASSEMBLY POWER	kW	25	38	46	58	28	40	46	58
主机外形尺寸(长×宽×高)APPEARANCE(L×W×H)	mm	2600×2000×2200	2900×2500×2300	3100×2500×2400	3500×2800×2500	2700×2000×2200	3100×2500×2300	3200×2800×2400	3500×2800×2600
机器重量WEIGHT	kgs	3600	4500	4800	5000	3800	4800	5000	5200
注：由于产品不断改进，以上数据仅供参考，如有更改恕不另行通知。
Note: Due to continuous product improvement, data above is only for reference, such as are subject to change without a separate notice.
