Single-layer Single-color model

WLCPJ系列-自动挤出吹塑机-单层单色平移式双工位机型-技术参数 WLCPJ series - Automatic Plastic Extrusion Blow Molding Machine-Single-layer Single-color Horizontal Double-station Models - Technical Parameters
型号MODEL		50I/50II	55I/55II	55III	60I/60II	70I/II	75I/II
制品最大容量MAX.CAPACITY OF PRODUCTIONS	L	1.00.3×2	1.50.5×2	0.3×3	1.50.75×2	3.01.5×2	6.02.0×2
模头中心距离CENTRAL DISTANCE OF DIE HEAD	mm	100	120	85	120	160	180
螺杆直径SCREW DIAMETER	mm	50	55	55	60	70	75
螺杆长径比SCREW LENGTH/DIAMETER RATIO	L/D	25/1	25/1	25/1	25/1	25/1	25/1
挤出量EXTRUSION VOLUME(PE)	kg/h	30	40	40	50	70	80
锁模力MOULD CLAMPING FORCE	kN	32	40	40	45	50	60
模板尺寸(宽×高)MOULD PLATE DIMENSIONS(W×H)	mm	260×240	350×350	350×350	350×350	400×380	400×380
开模行程OPENING STROKE	mm	150	250	150	250	280	280
主电机功率MOTOR POWER	kW	7.5	11	11	15	22	30
总功率GENERAL ASSEMBLY POWER	kW	22	26	26	30	42	55
主机外形尺寸(长×宽×高)APPEARANCE(L×W×H)	mm	2600×1900×2200	2700×2000×2200	2700×2000×2200	2900×2500×2300	3200×2800×2500	3500×2900×2600
机器重量WEIGHT	kgs	3500	3800	3800	4000	4800	5000
						直线导轨Linear Motion Guide
注：由于产品不断改进，以上数据仅供参考，如有更改恕不另行通知。
Note: Due to continuous product improvement, data above is only for reference, such as are subject to change without a separate notice.
